Features

• Two stage heating operation includes two stage gas valve, two stage inducer operation and 5 speed, direct drive STD ECM motor blower operation.
• Adjustable delay timer allows two stage operation with a single stage thermostat.
• Easily applied in upflow, horizontal left or right, or downflow installation with minimal conversion necessary.
• Compact, easy to install, ideal height 33" tall cabinet.
• Blower-off delay for cooling SEER improvement.
• Easy access to controls to connect power/control wiring.
• Built-in, high level self diagnostics with fault code display.
• Low unit amp requirement for easy replacement application.
• All models are convertable to use propane (LP) gas.
• Electronic Hot Surface Ignition saves fuel cost with increased dependability and reliability.
• 100% shut off main gas valve for extra safety.
• 24V, 40 VA control transformer/blower relay supplied for add-on cooling.
• Hi-tech tubular aluminized steel primary heat exchanger with stainless steel tube/aluminum fin secondary heat exchanger for outstanding efficiency.
• Solid removable bottom panel allows easy conversion.
• Airflow leakage less than 1% of nominal airflow at ductblaster conditions.
• No knockouts to deal with, making installation easier.
• Movable duct connector flanges for application flexibility.
• Quiet inducer operation.
• Inducer rotates for easy conversion of venting options.
• Fully supported blower assembly for easy access and removal of blower.
• External air filters used for maximum flexibility to meet customers IAQ needs.
• Insulated blower compartment for thermal and acoustic performance.
• 1/4 turn knobs provided for easy independent door removal.
• Internal condensate trap design (patent pending) provides condensate management options, easy visual operation check, and is self priming to prevent nuisance problems.
• Protection included from air intake, exhaust vent or condensate blockage.
• Venting applications maybe installed as either 2 pipe sealed combustion or single pipe vent using indoor combustion air.
